TM89P59

Data Sheet
DS-TM89P59_V11.pdf

4/1/2009
User manual
UM-TM89XXMCUFunction_EV12.pdf

5/9/2011
UM-TM89XXInstructions_EV11.pdf

5/29/2014
UM-4BIT Series Difference List_EV10.pdf

3/29/2021
UM-4BITinstructions_CV10.pdf

3/29/2021
UM-4BITMCUfunction_CV10.pdf

3/29/2021
Development Documnets
AP Notes

Development Tools
TICE87NB(已停產)
TICE89

GENERAL DESCRIPTION
The TM89P59 is a One Time PROM embedded high-performance 4-bit microcontroller
with LCD driver on a chip. It contains all the necessary functions, such as 4-bit
parallel processing ALU, ROM, RAM, I/O ports, timer, clock generator, dual clock
operation, Resistance to Frequency Converter(RFC), EL panel driver, LCD
driver, look-up table, watchdog timer and key matrix scanning circuitry on a
signal chip.
BLOCK DIAGRAM


FEATURES
1. Low power dissipation.
 1.5V/3V operating voltage range.
2. Powerful instruction set.
 Binary addition, subtraction, BCD adjustment. BCD can be executed
   directly in addition/subtraction operations.
 4 bits x 4 bits Multiplier
 Single-bit manipulation (set, reset, decision for branch).
 Various conditional branches.
 16 initial working registers and manipulators. (can be extended to all RAM
   with Page Mode)
 Look-up Table.
 LCD driver data transfer.
3. ROM Capacity. 32K x 16 bits.
 Instruction ROM Max. Capacity 32K x 16 bits.
 Table ROM Max. Capacity 32K / 16K x 8 / 16 bits.
4. RAM Capacity. 6K / 3K / 1.5K x 4 / 8 / 16 bits.
 LCD Max. Capacity 256 / 128 / 64 x 4 / 8 / 16 bits.
 STACK Max. Capacity 16 x 16 bits.
 HL/ZR store Max. Capacity 16 / 16 x 16 bits.
5. With direct/index addressing mode in data RAM access.
6. LCD driver output.
 16 common outputs and 64 segment outputs.
 1/4 ~ 1/16 Duty can be selected by mask option.
 1/3 ~ 1/5 Bias can be selected by mask option.
 Single instruction to turn off all segments.
 COM5 ~ 16 can be defined as CMOS or P_open drain type output port by
   mask option.
 External regulator mode for VL1/2 by mask option.
7. Input/output ports.
 Port IOA 4 pins (with internal pull-low, input signal chattering prevention
   circuitry).
 Port IOB 4 pins (with internal pull-low), and can be defined as KI1 ~ 4 by
   mask option.
 Port IOC 4 pins (with internal pull-low, low-level-hold, input signal
   chattering prevention circuitry).
 Port IOD 4 pins (with internal pull-low, input signal chattering prevention
   circuitry)
 Port IOE 4 pins (with internal pull-low).
8. Interrupt function.
 External factors 5 (INT pin, Port IOA, IOC, IOD & KI input).
 Internal factors 5 (Pre-Divider, Timer1, Timer2, Timer3 & RFC).
9. Built-in EL-light driver.
 ELC, ELP
10. Built-in Alarm, clock or single tone melody generator.
 BZB, BZ
11. Built-in resistance to frequency converter.
 CX, CX2, RFC0 ~ 5
12. Built-in key matrix scanning function.
 KO1 ~ KO16 (Shared with SEG1 ~ 16)
 KI1 ~ KI4 (Can be defined as IOB1 ~ 4 by mask option)
13. Three 6-bit programmable timer with programmable clock source.
 Read the content at any time
 Merge 2 or 3 timers into one 12-bit or 18-bit timer
 Used as a counter for RFC
14. Watchdog timer.
15. Built-in voltage charge halver & pump circuit.
16. Dual clock operation
 Slow clock oscillation can be defined as X’tal or external RC type oscillator
   by mask option.
 Fast clock oscillation can be defined as 3.58MHz ceramic resonator,
   internal R or external R type oscillator by mask option.
17. HALT function.
18. STOP function.
APPLICATION
Timer / Calendar / Calculator / Thermometer
