TM89P55M is a One Time PROM embedded high-performance 4-bit
microcomputer with LCD driver. It contains all the necessary functions, such as
4-bit parallel processing ALU, ROM, RAM, I/O ports, timer, clock generator, dual
clock operation, Resistance to Frequency Converter(RFC), EL panel driver, LCD
driver, look-up table, watchdog timer and key matrix scanning circuitry in a
signal chip.

1. Low power dissipation.
 1.5V/3V operating voltage range.
2. Powerful instruction set.
 Binary addition, subtraction, BCD adjustment. BCD can be executed
  directly in addition, subtraction operation.
 4 bits x 4 bits Multiplier
 Single-bit manipulation (set, reset, decision for branch).
 Various conditional branches.
 16 initial working registers and manipulators. (can be extended to all RAM
  by Page Mode)
 Table look-up.
 LCD driver data transfer.
3. ROM capacity. 16K x 16 bits.
 Instructon ROM Max. cpacity 16K x 16 bits.
 Table ROM Max. capacity 24K/12K x 8/16 bits.
4. RAM capacity. 4K/2K/1K x 4/8/16 bits.
 LCD Max. capacity 256/128/64 x 4/8/16 bits.
 STACK Max. capacity 16 x 16 bits.
 HL/ZR store Max. capacity 16/16 x 16 bits.
5. With direct/index addressing mode in data RAM access.
6. LCD driver output.
 Max 960 LCD dots by 16common outputs and 60 segment outputs.
 COM12~16 can be defined as SEG64~61 by option.
 SEG41~60 can be defined as
  IOB1~4,KI1~4,ELC,ELP,BZB,BZ,IOD1~4,IOC1~4 by option.
 1/4~1/16 Duty can be selected by option.
 1/3 ~1/5 Bias can be selected by option.
 Single instruction to turn off all segments.
 COM5~16 can be defined as CMOS or P_open drain type output by option.
 External regulator mode for VL1/2 by option.
7. Input/output ports.
 Port IOA 4 pins (with internal pull-low, input signal chattering
  prevention circuitry), and can be defined as CX,RFC0~2 by option.

 Port IOB 4 pins (with internal pull-low), and can be defined as SEG41~44
  by option.
 Port IOC 4 pins (with internal pull-low, low-level-hold, input signal
  chattering prevention circuitry), and can be defined as SEG57~60 by option.
 Port IOD 4 pins (with internal pull-low, input signal chattering prevention
  circuitry), and can be defined as SEG53~56 by option.
 Port IOE 4 pins (with internal pull-low), and can be defined as RFC3~5,CX2
  by option.
8. Interrupt function.
 External factors 5 (INT pin, Port IOA, IOC, IOD & KI input).
 Internal factors 5 (Pre-Divider, Timer1, Timer2, Timer3 & RFC).
9. Built-in EL-light driver.
 ELC, ELP. Can be defined as SEG49,50 by option.
10. Built-in Alarm, clock or single tone melody generator.
 BZB, BZ. Can be defined as SEG51,52 by option.
11. Built-in resistance to frequency converter.
 CX,RFC0~5,CX2. Can be defined as IOA1~4,IOE1~4 by option.
12. Built-in key matrix scanning function.
 KO1~KO16(Shared with SEG1~16)
 KI1~KI4. Can be defined as SEG45~48 by option.
13. Three 6-bit programmable timer with programmable clock source.
 Read out the content in anytime
 Merged 2 or 3 timers as 12-bit or 18-bit timer
 Used as counter for RFC
14. Watchdog timer.
15. Built-in voltage charge halver & pump circuit.
16. Dual clock operation
 slow clock oscillation can be defined as X’tal or external RC type oscillator
  by option.
 fast clock oscillation can be defined as 3.58MHz ceramic resonator, internal
  R or external R type oscillator by option.
17. HALT function.
18. STOP function.
Timer / Calendar / Calculator / Thermometer
