TM8761

1.	Powerful instruction set (137 instructions)
	Binary addition, subtraction, BCD adjustment, logical operation in direct and index addressing mode.
	Single-bit manipulation (set, reset, decision for branch).
	Various conditional branches.
	16 working registers and manipulation.
	Look-up table.
	LCD driver data transfer.
2.	Memory capacity
	ROM capacity		1024  x  16 bits.
	RAM capacity		    64  x    4 bits.
3.	Input/output ports
	Port IOA4			1 pin (with internal pull-low).
IOA4 port has built-in input signal chattering prevention circuitry.
	Port IOC			4 pins (with internal pull-low, low-level-hold).
	Port IOB3, 4		2 pins (with internal pull-low), & mask option with BZB, BZ.
4.	8-level subroutine nesting.
5.	Interrupt function
	External factor		1	(Pin IOA4 port).
	Internal factors		3	(Pre-Divider, Timer2 & RFC).
6.	Built-in Alarm, clock or single tone melody generator (BZB, BZ), & mask option with IOB3, 4.
7.	Built-in R to F Converter circuit
	CX, RR, RT.
8.	One 6-bit programmable timer (Timer 2) with programmable clock source.

9.	LCD driver output
	9 LCD driver outputs (Up to drive 36 LCD segments) .
	1/4 Duty and 1/2 Bias for LCD display.
	Single instruction to turn off all segments.
	9 DC/Open Drain outputs for LED mask option.
	16 LCD Address.
10.	Built-in Voltage double charge pump circuit.
11.	Clock oscillation can be defined as X’tal, external-R or internal-R 2 type oscillators by mask option.
12.	HALT function.
13.	STOP function.
