Operation Frequency
 6MHz crystal oscillation with internal 48MHz PLL.
 Internal RC oscillator 48MHz +/- 0.3% in USB mode
 STOP mode

On-Chip Memory
 8k x 14 internal program FLASH
 Internal 160 Bytes RAM at F-plane and two 64Bytes RAM at R-plane
USB interface
 Compliance with the Universal Serial Bus specification v2.0 Full Speed
 Built-in USB Transceiver, 3.3V regulator.
 Support USB Suspend /Resume and Remote Wakeup function
 Endpoint 0: Control SETUP/IN/OUT transfer (each 8 bytes)
 Endpoint 1: INTERRUPT IN transfer (8 bytes)
 Endpoint 2: INTERRUPT IN transfer (8 bytes)
 Endpoint 3: BULK-IN transfer with Ping-Pong feature (2*64 bytes)
 Endpoint 4: BULK-OUT transfer with Ping-Pong feature (2*64 bytes)
Timer
 Timer0 is 8-bit with 8-bit prescaler, Counter/Reload/Interrupt function
 Timer1 is 8-bit counter.
 Watchdog Timer clocked by built-in RC oscillator
 Wakeup Timer clocked by built-in RC oscillator
PWM:
 Support Pulse Width Modulation (PWM) function with 8-bit resolution.
Reset Controller
 Power On Reset, Watch-Dog Timer, USB Plug-out Reset
SPI interface
 Support Mode0, 1, 2, 3
 Master only
 Clock rate up to 6Mbps.
 Read/Write DMA mode
I80 Interface
 Compatible with 8-bit parallel interface
 Read/Write DMA mode

Touch Key
 5 channel touch pad
I/O Ports
 Max. 36 GPIOs to flexible application
LQFP48/ Die Form

     USB Standard Keyboard with auto-run function
 USB RF 2.4G Keyboard for PC
 USB IR Remote control with LCD Display for TV
 USB Touch pad function for keyboard
